Basic Parameters
| Battery Model | 51.2V280Ah / 51.2V314Ah |
| Battery Capacity | 14.3kwh / 16kwh |
| Maximum charge current | 200A@25+2°C |
| Maximum discharge current | 200A@25+2°C |
| Cycle life | 8000 cycles @25°C |
| Size(LxWxH) | 898x415x260mm |
Download
Active Balancing Function
Built-in 4-string 2A active balancing board, actively detects battery voltage differences, and distributes energy from high-voltage cells to low-voltage cells.
The active balancing function maximises the actual capacity of the battery, significantly slowing down battery degradation.
It protects the battery while providing customers with more energy.
Fuse
In addition to BMS protection, it is equipped with a built-in 400A fuse to prevent damage to the battery and BMS caused by sudden high currents.
Short-Circuit Switch
An internal 250A DC switch eliminates the need for customers to install additional protective switches when installing batteries and inverters.
High-efficiency Long-Life
More than 15 years designed lifespan, more than 8000 cycles (0.5C, 25°C).
Display
1.An internal colour touchscreen allows users to conveniently view battery capacity, battery temperature, charging and discharging currents, and the health status of each cell. Users can select the inverter communication protocol and view all battery information, etc.
2.The product includes an adapter for convenient programming and updating of the battery using a host computer.
